Feature:1. Dual Optical Fusion: Single infrared/visible light, edge blending, overlay fusion and PIP, automatic fusion of resolution without manual adjustment.2. Cold/Hot Capture and Multi-point Measurement: Automatic capture of center/highestlowest temperature points, more flexible for 3 temperature measuring points.3. 2.8" Full-view TFT High-definition Display: High-pixel and resolution (120x90) for clear display of remote/near heat source.4. HD Infrared Sensor: High-pixel infrared sensor for tracking cold/hot point, quick capture of thermal images and high definition display.5. 50 Large Wide Angle, Focusing-free and High Efficiency: Same distance covering larger measurement area, efficient measurement of whole circuit board, distribution cabinet and underfloor heating pipeline.6. Two-in-One Interface: One jack for transmission and charging, compatible with computer through Type-C, free for saving, view and comparing, supporting data export.7. Wide Application: Widely applied to equipment overhaul, HVAC pipeline inspection, photovoltaic equipment testing in electronic industry, vehicle maintenance and inspection, etc.Specification:Specifications:Model: NF-525Material: ABSHandheld Thermal ImagingResolution: 120 * 90Working Band: 8~14mFrame Rate: 25HzNETD: <60mK@25Field Angle: H=38° V=50°Emissivity: 0.01~0.99Temperature Measurement Range: Low Temperature: -10 ~160 High Temperature: 160~400Temperature Measurement Accuracy: ±2 or ±2% of the readingScreen Size: 2.8 inchesImage Mode: Edge blending, overlay blending, picture in picture, single infrared and single visible lightPalette: Iron red, white heat, black heat, rainbow, red heat, high contrast, green heat and lavaTemperature Measurement: Support full-screen temperature measurement of highest/lowest/center point and mild regionVisible LightVisible Light Camera: 1 million pixelsField Angle of Visible Light: H=55° V=83°Resolution: 720 PGeneralLanguage: Chinese (Simplifed), Chinese (Traditional), English, French, German, Spanish, Russian, Dutch, Japanese, Korean and ArabianInterface: USB Type-C (support charging and data transmission)Battery: 2600mAh lithium batteryCapacity: 8G internal memoryPicture Storage Format: JPGVideo Format: MP4Working Time: 4 hours if the battery is fully chargedWorking Temperature: -10°C~50°CStorage Temperature: -40°C~85°CItem Size: 219 * 72 * 66mm / 8.62 * 2.83 * 2.59inItem Weight: 292g / 10.29ozPackage Weight: 477g / 16.82ozPackage Size: 25.5 * 11.9 * 9.5cm / 10.03 * 4.68 * 3.74inPackage List:Package List:1 * Infrared Thermal Imager1 * USB Type-C Data Line1 * Color Box1 * Qualification Certificate/Warranty Card1 * Instruction Card of Lithium Battery1 * User Manual (English)
