Rated voltage frequency: 12-24V (DC)
Refrigerant: R134a
Working back pressure: low back pressure (L.B.P)
Motor type: BLDC
2. Working conditions
Ambient temperature: 0-43℃
Evaporation temperature: -35~-10℃
Working voltage range: 9.6~17/21.3~31.5V
Maximum exhaust pressure: 1.86 MPa (absolute)
Maximum condensation temperature: 65°C
Maximum winding temperature: 130°C
Maximum shell temperature: 95°C
Maximum exhaust temperature: 120°C
Startup performance: 12/24V[0.5/0.5MPa(abs)]
3. Compressor design parameters
Oil Type: Ester Oil
Refrigeration oil grade: RL22H
Oil injection volume: 150ml±10ml
Weight (with oil): 3.4kg±0.4kg
Suction tube diameter (inner diameter) 6.2 ± 0.1 mm
Exhaust pipe diameter (inner diameter) 5.0±0.1mm
Process pipe diameter (inner diameter) 6.2 ± 0.1 mm
Compressor noise≤40dB(A)
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
