Audiophile Mic Preamplifier, Voice Processor and 192 kHz USB/Audio Interface

ULTRAVOICE UV1

When it comes to vocals, sound engineers become critical and often prefer a channel strip over a mixing console because of its outstanding sound quality and flexibility. The ULTRAVOICE UV1 is a full-featured channel strip with high-end microphone preamplifier, versatile sound processing features, and the free choice to play out the processed sound via balanced analog outputs or pass it on to the internal USB interface.

Midas Mic Preamp – Legend Inside!

Did you know that Midas is one of the most recognized brands used by audio professionals around the world? Now you can get the gear the pros use! ULTRAVOICE UV1 comes with a state-of-the-art Midas microphone preamplifier with +48 V phantom power, ultra-low noise, high gain and audiophile quality.

Crystal Clear Signal Path at 192 kHz

The ULTRAVOICE UV1 is more than just a mic preamp and voice processor – we added one of the best USB audio interfaces with the highest possible resolution and lowest latency. Full 192 kHz sampling rate at a clear 24-bit resolution will make you smile listening to the astonishingly crisp sound you’ll get.

Zero Latency Monitoring

Recording the voice is one of the most critical tasks in the studio. Singers are very sensitive to delays. A few milliseconds can make all the difference between a good or a great take! So, we added this simple but very effective monitoring section to the ULTRAVOICE UV1. Blend between direct input signal and USB playback makes it easy to find the best balance while you're recording. Just plug in your headphones and adjust the volume.

Digital or Analog? – Both!

Some people prefer to stay in the analog domain, some prefer the shorter path to record directly to the digital. On the ULTRAVOICE UV1 you will get both – simultaneously!

Connect your PC or Mac directly via USB to get the best vocal sound without detours into your DAW. Connect any analog outboard equipment to the balanced outputs for further signal flow. It’s up to you.

Sound P-R-O-C-E-S-S-I-N-G

A high-quality microphone preamp and a brilliant USB interface are the most important tools to integrate vocals perfectly into a song arrangement. Just press the BYPASS switch to get the pure experience.

But sometimes you want to pimp your vocals for the best result. And here we go! The ULTRAVOICE UV1 features all kind of processing you will need – a Compressor for more punch, a De-Esser to remove sibilants, an Enhancer for dynamic sound details at the lower and upper end of the frequency spectrum, an Expander/Gate to “mute” automatically unwanted surrounding noise and finally the amp to gain lost levels again.

And even if this would be not enough you can insert additional outboard gear for even more sound improvements.

Stage – Studio – Stream

It doesn’t matter what your target application is. The ULTRAVOICE UV1 is a perfect match for any environment where the best quality for your voice as a singer, narrator, moderator will be required. Put it in a live rack to go on tour, install it in a musical theater for the main artists, make it the center of your home studio or broadcast streaming environment, or unload your mixing console at the recording studio.

The ULTRAVOICE UV1 is the ideal solution for home or professional studios, or as part of a larger setup, on stage or on tour. Premium, ultra-low noise components and high headroom lets your music shine at its best – this is especially true for the most critical source: Vocals!

High Quality, Best Value

We designed the ULTRAVOICE UV1 to provide many years of super-clean, high-fidelity performance in the most critical listening environment – yours! Built from the highest-grade components, the UV1 is the perfect way to add a lot more convenience and control into your current studio setup.

Check out the amazing ULTRAVOICE UV1 at your local Behringer dealer or get yours online today. Easy has never sounded better!

Specification

Inputs

          Mic input

    Discrete mic preamp

Type: Balanced XLR/TRS combo connector

Impedance: 4 kΩ

Max input level: +17 dBu

Equivalent input noise (EIN): -126 dBu, 20 Hz - 20 kHz, 150 Ω

          Line in

    ¼" TRS, balanced

Impedance: 10 kΩ unbalanced, 20 kΩ balanced

Max input level: 30 dBu

          Insert return

    ¼" TRS, balanced

Impedance: 5 kΩ

Max input level: +21 dBu

Outputs

          Line out

    Balanced XLR, ¼" TRS

Impedance: 100 Ω unbalanced, 200 Ω balanced

Max output level: +20 dBu

          Insert send

     ¼" TRS, balanced

Impedance: 100 Ω unbalanced

Max output level: +20 dBu

Controls

          Mic preamp

    Gain: Mic: 0 to +60 dB, line: -15 to +45 dB

48 V: +48 V phantom power, switchable

Low cut:  -18 dB/oct @ 80 Hz

          Compressor

    Drive: Threshold, -40 dB to +20 dB

Density:  1 to 75 dB/sec

          De-Esser

    Frequency:  800 Hz to 10 kHz

Threshold: Program-dependent

Release time: Program-dependent, approx. 1 ms/dB

          Enhancer

    LF/HF detail:  Min to max boost (0 dB to +12 dB)

          Expander/Gate

    Threshold: Off to +15 dB

Ratio:  1:1 to 10:1

          Output

    Output gain: -30 to +10 dB

          Monitor

    Mix: Blend direct signal and playback

Level:  -∞ to +6 dB

System

          Frequency response

    <10 Hz to 80 kHz (0/-3 dB)

          Dynamic range

    110 dB, A-weighted

USB

          Type

    USB 2.0, type B

          Interface

     2 in / 2 out

          Converter

    24-bit

          Sample rates

     44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz

          Supported operating systems

    Windows 10 / Mac OS X 10.4 or higher

          Drivers

     Windows driver available on behringer.com, no drivers needed for Mac

Power

          Switch-mode autorange power supply

    100-240 V, ~50/60 Hz

          Power consumption

    15 W

          Mains connection

    Standard IEC connector

Physical

          Standard operating temperature range

    5° C – 45° C (41° F – 113° F)

          Dimensions

    483 x 150 x 44 mm (19 x 5.9 x 1.7")

          Weight

    1.5 kg (3.3 lbs)
