Detection Range
|
100-2000mm
|
|
Adjustment range
|
100-2000mm
|
|
Unusable area
|
0-100mm
|
|
Transducer Frequency
|
180K Hz
|
|
Response delay
|
85ms
|
|
Operating voltage
|
10…30VDC,ripple10%ss
|
|
Current Consumption
|
≤20mA锛圢o-load锛�
|
|
Output Type
|
1 switch output PNP NO/NC,programmable
|
|
Resolution
|
0.11mm at max.sensing range
|
|
Deviation of the characteristic curve
|
±1% of full-scale value
|
|
Repeat accuracy
|
±0.1% of full-scale value
|
|
Load impedance
|
>1k Ohm
|
|
Maximum switching current
|
200 mA (reverse polarity protection)
|
|
Temperature influence
|
±1.5% of full-scale value
|
|
Ambient temperature
|
-25…70鈩�
|
|
Storage temperature
|
-40…85鈩�
|
|
Connection
|
Connector M12x1,4-PIN
|
|
Housing Material
|
PA-GF35
|
|
Transducer Material
|
epoxy resin/hollow glass sphere
mixture; Polyurethane foam |
|
Weight
|
120g
|
|
IP Rating
|
IP65
|
|
Out packing size
|
40*40MM
|
|
Standard conformity
|
EN 60947-5-2:2020
|
