model
|
DP10007
|
DP10013
|
DP20003
|
||
|
bandwidth
|
100MHz
|
100MHz
|
100MHz
|
||
|
Rise Time
|
≤3.5ns
|
≤3.5ns
|
≤3.5ns
|
||
|
attenuation
|
10X
100X |
50X
500X |
200X
2000X |
||
|
precision
|
±1%
|
±2%
|
±2%
|
||
|
Maximum input difference voltage((DC+AC PK)
|
70V(10X)
700V(100X) |
130V(50X)
1300V(500X) |
560V(200X)
5600V(2000X) |
||
|
Maximum Common Mode Input Voltage
|
CAT Ⅱ 600V
CAT Ⅰ 1000V
|
CAT Ⅱ 1000V
|
CAT Ⅲ 1000V
|
||
|
reference noise
|
≤15mVrms(10X)
≤60mVrms(100X) |
≤40mVrms(50X)
≤230mVrms(500X) |
≤160mVrms(200X)
≤920mVrms(2000X) |
||
|
input resistance
|
8MΩ/1.25pF (differential) 4MΩ/2.5pF (single-ended to ground
|
10MΩ/1pF (differential) 5MΩ/2pF (single-ended to ground)
|
50MΩ/1.25pF (differential) 25MΩ/2.5pF (single-ended to ground)
|
||
|
power
|
1.25W
|
0.85W
|
0.85W
|
||
|
Overload Indication
|
|
|
|
||
|
power supply
|
DC 5V, USB powered
|
|
|
||
|
The output voltage
|
≤3V
|
|
|
||
|
Size
|
14.5cm*6cm*2.7cm
|
|
|
||
|
|
About 45cm
|
|
|
||
|
|
About 90Cm
|
|
|
||
|
temperature
|
0℃~40℃
|
|
|
||
|
Working humidity
|
10%~85%
|
|
|
||
