Features:
> Embedded design with mini size
> Metal case and waterproof, conform to lP66
> User capacity: Supports up to 100 fingerprints and 3000 cards.
> Card type: 125KHz EM card
> One programmable relay operation
> Latch mode to hold door or gate open
> Tri-colour LED status display
|
User Capacity |
100 Fingerprints and 3000 Cards |
|
Operating Voltage |
DC9~18V |
|
Idle Current |
≤25mA |
|
Active Current |
≤100 |
|
Proximity Card Reader |
EM |
|
Radio Technology |
125KHz Proximity Card |
|
Read Range |
2cm |
|
Wiring Connections |
Relay Output, Exit Button |
|
Relay |
One (NO, NC, Common) |
|
Adjustable Relay Output Time |
o-99 seconds (5 seconds default) |
|
Lock Output Load |
2 Amp Maximum |
|
Environment |
Meets lP66 |
|
Operating Temperature |
-25℃~60℃ (-13°F ~140°F) |
|
Operating Humidity |
20%RH-98%RH |
|
Physical |
Zinc-alloy plate |
|
Colour |
Silver |
|
Dimensions |
|
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
