1. Technical indicators:
Operating frequency: 70-110MHz (FM signal)
Supply voltage: 20-30V (24V)
Power supply current: 5.0A (varies with output power)
Power gain: 16dB (typical value)
Input power: 3-5W (customizable)
Output power: 50dBm (typical value of 100W)
47dBm-50.0W@20V Power supply, input 4W.
48dBm-65.0W@22V Power supply, input 4W.
49dBm-80.0W@24V Power supply, input 4W.
50dBm-100.W@28V Power supply, input 4W.
51dBm-125.W@31V Power supply, input 4W.
System impedance: 50 ohms
Joint form: SMA-K
Product weight: 250g
Dimensions: Length 100mm X Width 50mm X Height 60mm
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
