DIY Supplies : ELECTRICAL
Brand Name : FNIRSI
Origin : Mainland China
Display screen : 2.4 inch TFT color screen
Supply voltage : Rechargeable lithium battery
Charging specifications : Type-C 5V
Bracket specifications : All-in-one foldable stand
Real-time sample rate : 10MSa/s
Analog Bandwidth : 500Khz
Input resistance : 1MΩ
Coupling method : AC/DC
Test voltage range : 400V
Vertical Sensitivity (x1) : 10mV-10V
Horizontal time base range : 1us-10s
Trigger mode : Auto / Normal / Single
Trigger type : Rising edge / Falling edge
Waveform Freeze : Yes
Automatic measurement : Yes
Diodes : Forward voltage drop <4.5V
Reglulated diode : 0.01~4.5V
MOSFET : JFET IGBT MOSFET
SCR : Turn-on voltage <5V, gate Pole trigger current <6mA
Capacitor : 5pF~100mF
Resistor : 0.01Ω~50MΩ
Inductor : 10uH~1000mH
Battery : 0.1~4.5V
Input voltage : 0~40V
DS18B20 : 0-85℃
DHT11 : 0-60℃/5-95%
Infrared remote decoding : NEC protocol infrared code
Triangle wave : 1-10KHz/0-3.3V/50%,1-10KHz/0-3.3V/50%
Square wave : 1-100KHz/3.3V/50%
Pulse wave : 1-100KHz/3.3V/0-100%
Ramp : 1-10KHz/0-3.3V/0-100%
DC : 0-3.3V
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
