Firmware
Bluejay: G-H-30-96-v0.16/ BLS:G-H-30 16.7
Continuous /Burst Current
45A x 4/ 50A x 4
Input Voltage
2~6S Lipo(8.4~25.2V)
Telemetry
No
ESC Programming
Bluejay(default)/BLHeli-S optional
Stick Programming
Supported
Current sensor:
Supported
Current scale:
100
Input signal:
Dshot300/600
Model
FOXEER Reaper AIO V2
CPU
STM32F745
Power Supply
2~6S Lipo(8.4~25.2V)
BEC Output
DC5V/2.5A
OSD
BF OSD
Black Box
16M Flash Memory
UART
5 Set
USB
Micro USB
Fireware
BF:FOXE-FOXEERF745V2_AIO
DJI/Vista Connector
Supported, 7pin
Size
32.5X32.5mm
Mounting Hole
25.5X25.5mm,Φ3mm/M2
Weight(g)
8.6g
Working Temperature
-20℃ ~ +55℃
Working Humidity
20～95%
Storage Temperature
-20℃ ~ +70℃
Package Includes
1*AIO, Rubbers Columns, XT30 Cable, Vista Cable, Capacity
