Transmit: 136-174/350-390/400-520MHz
Aviation frequency band: 108-136MHz
Receive: 76-108/136-180/230-250/350-400/400-520/800-870MHz
Number of channels: 199
Channel spacing: 25KHz (broadband), 12.5KHz (narrowband)
Frequency stability: ±2.5ppm
Working voltage: 7.4VDC±20%
Working temperature: -20Celsius-+60Celsius
Antenna impedance: 50Q
Weight: 280g (including battery antenna)
Waterproof grade IP68
launch part
Broadband
High power transmission
Modulation mode 16K in F3E
Adjacent channel power greater than equal 65dB
Signal-to-noise ratio less than equal -40dB
Spurious and harmonics less than equal 65dB
Spurious emission less than equal -36dBm
Audio response 300Hz-3KHz
Audio distortion less than equal 5%
narrow
High Power
Modulation mode 8K in F3E
Adjacent channel power greater than equal 60dB
Signal-to-noise ratio less than equal -40dB
Spurious and harmonics less than equal 60dB
Spurious emission less than equal -36dBm
Audio response 300Hz-3KHz
Audio distortion less than equal 5%
receiving part
Broadband
Sensitivity -120dBm
Intermodulation greater than equal 60dB
Adjacent channel selectivity greater than equal 60dB
False signal response greater than equal 60dB
Audio response 300Hz-3KHz
Signal-to-noise ratio greater than equal 60dB
Audio distortion less than equal 5%
Audio output power 1W
Colour:black/ArmyGreen
Material:PC
Size:138 x 62 x 40mm
Package Contents:
1 set x walkie-talkie
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
