IFlight ProTek R25 Analog BNF With SucceX Mini Force 600mw With Caddx C01 FPV Camera ELRS 2.4G Kit

        Rack Model: ProTek R25

Structure: wide X structure

Rack wheelbase: 113mm

Overall frame size: 143mm*158mm

Empty weight: /

Arm thickness: 2.5mm

Plate thickness: /

Bottom plate thickness: 2.5mm

Top plate thickness: 1.5mm

Support flight control: 25.5mm*25.5mm hole position flight control

Support camera: CADDX C01/14mm wide camera

Recommended motor: 14xx series motor

        VTX

Model: SucceX mini Force 600mw/CADDX C01

Propeller: Nazgul Cine 2525

AIO (flight control and ESC integrated):

Outer size: 30.5*30.5mm

Hole size: 25.5*25.5mm/φ3mm

USB Type: Micro-USB

Weight: 7.4g

MCU: STM32F411

Gyro: BMI270

Blackbox: 8MB

BEC output: 5V 2A

INA pad: n uart2

Barometer: /

ESC current support: 20A (continuous), 25A (instantaneous)

Voltage input: 2-4S

Current sensor: yes

BLHeli: BLHeli-S

Telemetry: no

FC Firmware: IFLIGHT_F411_PRO

Config: IFLIGHT_F411_PRO.config

ESC Firmware: Q-H-15

Firmware Version: 4.2.11

Analog VTX: SucceX Mini Force 600mw / C01 FPV Camera

        ProTek R20 BNF Specs:

        *VTX: SucceX Mini Force 5.8GHz 600mW VTX Adjustable

        *Weight: 89.2g (without battery)

        *Bottom plate thickness: 2.5mm

        *Motor: XING-E 1105 6500KV

        *Top plate thickness: 1.5mm

        *Body Size: 132mm*122mm

        *FC pattern: 25.5*25.5mm

        *FPV cam spacing: 14mm

        *Whoop F4 AIO 1.1(LINK)

        *Arm Thickness: 2.5mm

        *Propeller size: 2 inch

        *Wheelbase: 94mm

        Specifications:

        AIO//Whoop AIO F4 V1.1 AIO

        Mounting pattern: 25.5*25.5mm/φ3mm

        Firmware Target: IFLIGHT_F411_PRO

        Constant current: 20A，25A (Burst)

        Config：IFLIGHT_F411_PRO.config

        Connector: Micro-USB

        ESC Firmware: Q-H-15

        Current sensor: yes

        BEC output: 5V 2A

        ESC Telemetry: NO

        Size: 30.5*30.5mm

        MCU: STM32F411

        BLHeli: BLHeli-S

        Barometer: NO

        Blackbox: 8MB

        Gyro: BMI270

        INA pad: nR2

        Weight: 7.4g

        Input: 2-4S

        VTX//SucceX Mini Force 5.8GHz 600mW VTX Adjustable

        -Power: PIT/25/200/400mW/600mW

        -Antenna interface: MMCX

        -VTX protocol : IRC Tramp

        -Output 40 channels.

        -Size: 29*29mm

        -Mounting pattern: 20*20Φ3/25*25 mmΦ2

        -Weight: 4g

        ProTek R20 Analog Quad BNF Included Components and Parts

        pre-built and tested Quadcopter

        1 x iFlight Lipo Strap 10*150mm (Color May Vary)

        2 x HQ 2*2*3 (Set of 4 - Color May Vary)

        1 x ProTek R20 Analog BNF
