Specifications:
Sine wave: 0.01Hz --- 30MHz (minimum resolution 0.01Hz)
Square wave: 0.01Hz --- 25Mhz (minimum resolution 0.01Hz)
Triangular wave: 0.01Hz -- 25Mhz (minimum resolution 0.01Hz)
Other waveforms: 0.01Hz --- 6MHz (minimum resolution 0.01Hz)
Custom waveform: 1Hz ------ 6MHz (minimum resolution 1Hz)
Square wave rise time:<=10ns
Waveform type:
Self defined waveform:
Square wave sine wave triangular wave trapezoidal wave exponential wave half sine wave positive and negative triangular wave ring wave, etc. 98 (waveform drawn by the user)
Number of waveform points: 2048 (maximum)
Maximum output frequency of waveform: 150MSa/s
Vertical resolution: 14 bits
Square wave overshoot:<=5%
Square wave duty cycle: 0% - 100%
Output signal amplitude range:
<=5MHz (2mV ----20V)
>=5MHz<=10MHz (2mV ---- 10V)
>=10MHz<=30MHz (2mV ---- 5V)
Minimum amplitude: 2mv
Minimum amplitude increment: 1mv
Offset range of output signal:<=500mV (-+1V (total maximum)),>500mV (-+10V (total maximum))
Minimum offset increment:
Adjustable phase: 0 ° ---- 360 °
Minimum phase increment: 1 °
Sweep channel: CH1 CH2 (simultaneous)
Sweep type: linear
Sweep time: 200ms --- 999.9s
Minimum step of sweep time: 100ms
Setting range: corresponding frequency of each built-in waveform
Sweep mode: forward sweep and reverse sweep
Sweeping channel: CH1 CH2 (simultaneous)
Sweep type: linear
Sweeping time: 200ms --- 999.9s
Minimum step of sweep time: 100ms
Setting range: corresponding amplitude of each built-in waveform
Sweeping mode: forward scanning and reverse scanning
Waveform output impedance: 50 Ω -+10%
Frequency meter: input 1Hz ------ 10OMHz (input voltage range 200mV-20V)
