Specifications:
Model: KP184
Power supply input:
Voltage: AC 110V/220V ± 10%, 50 ± 2Hz
Power consumption:<20w
Load input:
Load voltage: DC 1-150V
Load current: 0-40A
Load power: 0-400W
Measurement accuracy:
Current: ± 0.05%+5mA
Voltage: ± 0.05%+5m
Control accuracy:
Current: ± 0.05%+5mA
Voltage: ± 0.05%+5mA
Communication mode: RS232/RS485
Protection:
Overvoltage (ov): greater than 152V, close with load
Over temperature (OT): 85 ℃
Overpower (OP): single channel 410W
Operating ambient temperature range: 0~50 ℃
Operating environment humidity range: 10~90% RH
Withstand voltage of DC input end to chassis:+500VDc
Insulation resistance of DC input end to chassis:>20MΩ, 500VDC
Insulation resistance of AC input end to chassis:>20MΩ， 500VDC
Overall dimension L * B * H (mm): about 300 × ninety × one hundred and ninety
Weight (about): 4.5KG
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
