Product Name:
Function description and requirements: The battery must be brought before testing
Glasses on/off/display light:
(1) Power on: Long touch MFB, power on for 3 seconds (flashing traffic lights) (prompt tone: Power on/Power on)
(2) Shutdown: Touch MFB for 3 seconds in the power-on state, and the red light will stay on for 2 seconds (prompt tone: Shutdown/Power off). It has been turned off
Glasses phone successfully connected display light:
Reminder of Bluetooth disconnection between glasses and mobile phone:
Touch function:
(1) After startup: Double click to switch between Chinese and English
(2) Touch: pause/play/answer/hang up
(3) Long press 2S: Wake up Siri
(4) Automatic shutdown: 5 minutes (prompt tone: shutdown/Power off)
Product Support Configuration Function: (1) 3D noise reduction, (2) microphone, (3) memory card, (4) phone 0TG data cable interface type-c, (5) PC-CAM, (6) charging recording
Recording on mode: on/off :
(1) No memory card status: Press and hold the power button for 3 seconds to turn on, the blue light is on, and the TF card is not present. The blue light flashes 5 times and automatically shuts down
(2) Memory card status: Press and hold the power button for 3 seconds to turn on the device, the blue light remains on for 6 seconds, and the light turns off to enter recording mode. During recording, there is a cycle of coverage, with 5 minute intervals. Resolution: 2048 * 1152 Video encoding: H.264 Video format: MP4 Stop recording: Click the power button, the blue light turns on, exit recording, and save the video. Shutdown: Press and hold the power button for 6 seconds, and the blue light will flash 5 times to turn off the power off
Photography mode: The blue light is constantly on. Double click the power button once, and the blue light flashes once and then remains on, indicating that the photo is taken once. Image resolution 3840 * 2160 Image format: JPG
Recording during charging: Charging display: The red light remains on, while the green light remains on when fully charged. Recording during charging: Press and hold the on/off button for 3 seconds, and the blue light will turn on and off to directly enter the recording mode. Click the on/off button to stop recording and save the video. (The red light/blue light remains on) Enter the standby mode. Double click the on/off button to take a photo, and the recording cycle will cover it. There will be no memory card in 5 minutes. The red light will stay on for charging when powered on, and the blue light will stay on for 10 seconds after long pressing the power on button for 3 seconds. After flashing for 5 times, the device will shut down. The red light will turn off when fully charged, and the green light will stay on for a long time. Voltage: 4.15-4.20
