Precautions

   IMPORTANT

   Do not plug in an appliance where the load exceeds 10AMP Always ensure the plug of any

   applance is fully inserted into the timer outlet. If cleaning of the timer is required, remove

   from mains power and wipe timer with a dry cloth

   DO NOT IMMERSE TIMER IN WATER OR ANY OTHER LIQUID Heaters and similar

   appliances should never be left unattended during operation. The manufacturer recommends

   such apliances not be connected to timers

  specification:

   BRIEF INTRODUCTION

   I The timer has a total of 16 ON/OFF programs

   2. Manual on/auto/manual off can make settings as required very easily

   3. 15 combinations of day or blocks of days are available for the timer as follow

   MO TU WE TH. FRSA. SU

   MO

   TU

   WE

   TH

   FR

   SA

   SU

   MO WEFR

   TUTH.SA

   SA.SU

   MO TU. WE

   THFR.SA

   MOTU WE TH.FR

   MOTU WETH.FRSA

  Application range:

 1. Wetting and rust removal

 2. Air humidification

 3. Chemical treatment

 4. Chemical spraying

 5. Liquid spraying

 6. Tobacco leaf humidification

 7. Tablet coating

 8. Flue gas evaporative cooling

 9. Disinfection

 10. Unit cooling

 11. Fruit wax spray

 12. Ceramic tile glazing

 13. Factory humidification

 14. Salt fog test

 15. Artificial fog

 16. Humidification in other places

   INITIAL OPERATION

   1. Plug the timer into a regular 220-240 Volt housrhold power point and turn the

   power on..

   2. Leave for approximately 12 hours to charge the memory back up batteries

   3. After charging clear all current information by pressing the"R button with a sharp

   object such as a pen or pencil.

   4. The timer is now ready to be set up for ise

   SETTING CURRENT TIME

   1. Press the CLOCK button and hold simultaneously press the week button until

   actual day is displayed. Continue by pressing HOUR or MINUTE button until th o

   current hour or minute is displayed. When setting the buttons week hour or minute can

   be held down for rapid forward counting

   oth buttons. The week and time will be

   elease Do

   2. Re

   e set

   3. To reset incorrect time repeat previous steps

  Notes:

 1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!

 2. Please allow 1-3cm measuring deviation due to manual measurement.
