Low Profile Compact Design
High Torque Three-Pole Ferrite Motor
Durable Nylon Gears
Top Ball Bearings
Operating Voltage Range (Volts DC):4.8V ~ 6.0V
Speed (Second @ 60°):0.18 ~ 0.14
Maximum Torque Range oz. / in.:61 ~ 76
Maximum Torque Range kg. / cm.:4.4 ~ 5.5
Current Draw at Idle:8 mA
No Load Operating Current Draw:250 mA
Stall Current Draw:800 mA
Dead Band Width:8 µs
Dimensions (Inches):1.73 x 0.90 x 0.98
Dimensions (Metric):44.0 x 23.0 x 25.0
Weight (Ounces):1.23
Weight (Gram):35.0
Circuit Type:HT7003 Analog SMT
Motor Type:3 Pole Metal Brush Ferrite
Gear Material:Nylon
Bearing Type:Top Ball Bearing
Output Shaft (type / Ømm):Standard 24
Case Material:Plastic
Dust / Water Resistance:Splash Proof
Connector Gauge (AWG) / Strand Count:25 / 40
