Features：
- Frequency Range from 9 kHz up to 1.5 GHz
- -160dBm Displayed Average Noise Level
- Phase Noise -98dBc/Hz @1Gz and offset at 10KHz
- Total Amplitude Accuracy <1.5dB
- 10Hz Minimum Resolution Bandwidth (RBW)
- EMI Pre-compliance Test Kit, optional EMC test software
- Standard Pass/Fail on-site test alert ability
- Up to 7.5 GHz Tracking Generator Kit
- 10.4 inches display
Specifications:
Resolution
1Hz
Frequency Span
Range
0 Hz，100 Hz to maximum frequency of device
Accuracy
± span /（swept points -1）
Internal Reference
Reference Frequency
10.000000 MHz
Reference Frequency Accuracy
±[（days from last calibrate × freq aging rate）+ temperature stability + initial accuracy ]
Temperature Stability
<2.5ppm（15℃ to 35℃）
Aging Rate
<1ppm/year
Readout
Marker Frequency Resolution
span/（the number of sweep points -1）
Uncertainty
±（freq indication × freq reference uncertainty +1%× span +10%× resolution bandwidth + Marker Frequency Resolution）
Frequency Counter
Resolution
1 Hz，10 Hz，100 Hz，1 kHz
Accuracy
±（marker freq × freq reference uncertainty + counter resolution）
BandWidth
Resolution Bandwidth (-3 dB)
10Hz to 500kHz（in 1 to 10 sequence）， 1MHz，3MHz
Resolution Filter Shape Factor
<5：1 nominal（Digital implement, similar to Gauss Pattern）
Accuracy
<5% nominal
Video Bandwidth (-3 dB)
10Hz to 3MHz
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
