Main features:
Using Time Division Multiple Access
(TDMA) Digital function
Dual time slot repeater
Pointtopoint dual time slots
Firmware Upgradable
Working alone
Encryption function
Compatible with Mototrbo Tier I&II
Single call, group call, and full call
Combination of analog and digital
Remote kill/stun and activate
Up to 3000 channels
Transmission interruption
Group call matching (mixed)
record
Emergency alarm
VOX
TOT
General specifications
Frequency 136-174&400-480MHz
Channel 3000
Frequency stability ± 1ppm
Working temperature -30 ℃~+60 ℃
Working voltage 7.4V DC
Size 131 x 61 x 36mm
Weight 258g (including battery)
Battery type Lithium ion
Battery capacity 2000mAh
Antenna impedance 50 Ω
Audio impedance 1W@16 Ω
Channel spacing 12.5KHz
Vocoder AMBE+2 ™
transmitter
High power ≤ 5W, low power ≤ 1W
Frequency stability ± 1.0ppm
Adjacent channel power ≤ -60dB
Idle time slot power TDMA: ≤ 57dBm
Buzzing and noise -40dB@12.5KHz
Stray radiation antenna: 9KHz-1GHz ≤ -36dBm
1GHz-12.75GHz ≤-30dBm
FM modulation method 11K0F3E@12.5KHz
4FSK digital mode 12.5KHz (data only): 7K60FXD
12.5KHz (data and voice): 7K60FXW
Passive time slot power -57dBm
Digital Protocol ETSI-TS102 361-1, -2, -3
Audio response+1~-3dB
Modulation BER (bit error rate) ≤ 5%
Recipient
Analog sensitivity 0.2 µ V @ 12dB SINAD
Digital sensitivity 0.25 µ V (BER: 5%)
Adjacent channel selectivity ≤ -60dB@12.5KHz
Intermodulation ≤ 60dB
Stray response ≥ 70dB
Audio response+1~-3dB
Rated audio distortion<5%
Rated audio power 1W
Modulation ≥ 45dB@25KHz
≥40dB@12.5KHz
Accessories include:
1 x Host
1 battery
2 x antennas
1 adapter
1 charger
1 x User Manual
1 x belt clamp
1 x lifting rope
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
