| Serial number | Function items | option | describe | Serial number | Function items | option | describe |
| 1 | Standard | • | DMR number | 9 | Charging method | • | TYPE-CDirect charging(Seat charger - optional) |
| 2 | Keys | • | Mechanical buttons | 10 | Write frequency interface | • | Jianwu Double Needle |
| 3 | frequency range | • | 446.0-446.2 MHZ | 11 | Antenna mode | • | Fixed antenna |
| 4 | Power/Switching | • | 0.5W | 12 | Battery capacity | • | 2000mAh |
| 5 | Number of channels | • | 13 | Audio interface | • | Jianwu Double Needle | |
| 6 | Write frequency software | • | Refer to factory settings | 14 | |||
| 7 | Scheme chip | • | C7000 | 15 | |||
| 8 | 16 | ||||||
| Digital/Analog Section | |||||||
| Serial number | Function items | option | describe | Serial number | Function items | option | describe |
| 1 | bandwidth | • | 12.5Hz | 10 | Channel lock | • | The software setting lock function is turned off by repeatedly pressing the "beep" button for 2 seconds. |
| 2 | VOX | • | Software defined side keys 1-9 levels, press VOX on or off for 2 seconds | 11 | Remote Death/Resurrection | • | Realize remote death and resurrection |
| 3 | Battery Save | • | automatic recognition | 12 | CTCSS/DCS | • | Standard Asian pronunciation, CTCSS: 50 sets/DCS: 210 sets |
| 4 | Low battery alarm | • | Prompt sound | 13 | Squelch level | • | Normal/Strict |
| 5 | T0T limited time | • | ≤ 180s | 14 | Private call | • | AES 128 encryption |
| 6 | monitoring | • | Press and hold the setting button for 2 seconds, then turn on/off the button | 15 | |||
| 7 | Alarm | • | Can set single key shortcut keys | 16 | |||
| 8 | Voice Announcements | • | 17 | ||||
| 9 | Voice control delay | • | 0.5-3 seconds | 18 | |||
| Serial number | specifications | parameter | Serial number | specifications | parameter |
| 1 | frequency range | 446.0-446.2 MHZ | 5 | working voltage | DC3.7V |
| 2 | Battery capacity | 2000mAh | 6 | Antenna impedance | 50 Ω (Ushaped antenna) |
| 3 | Audio power | 1W | 7 | Product size | 34 * 58.5 * 190mm (including antenna) |
| 4 | working temperature | -20℃~60℃ | 8 | ||
| Receiving part | |||||
| Serial number | specifications | parameter | Serial number | specifications | parameter |
| 1 | Receiving sensitivity | Simulation ≤ -121dBm@12dB SINAD; Number ≤ -119dBm@5 % BER | 7 | Adjacency selectivity | ≥60dB |
| 2 | Modulation reception bandwidth | 12.5KHZ | 8 | Audio output | 1w |
| 3 | intermodulation | -65dB | 9 | Receiving current | ≤500mA |
| 4 | Audio distortion | ≤5% | 10 | Standby current | ≤160mA |
| 5 | Audio response | 300-3KHZ, +1/-3dB | 11 | ||
| Launch section | |||||
| Serial number | specifications | parameter | Serial number | specifications | parameter |
| 1 | Transmitting power | 0.5W | 7 | Stray radiation | ≤-57dBm |
| 2 | Narrowband: ≤± 2.5kHz@12.5KHZ | 8 | modulation mode | eleven K0F3E@12.5KHz | |
| 3 | Emission current | ≤750mA | 9 | Signaltonoise ratio | ≥40dB@12.5KHz |
| 4 | Adjacent channel power | ≤-60dB@12.5KHZ | 10 | residual FM | ≥40dB@12.5KHz |
| 5 | Modulation distortion | <5% | 11 | Frequency stability | Shi 0.5 ppm |
| 6 | block | ≥84dB | 12 | ||
| Accessories section | |||||
| Serial number | specifications | parameter | Serial number | specifications | parameter |
| 1 | charging stand | Input: 5V/500mA | 7 | ||
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
