Product Features:
1. Visually displays measurement value and state
2. Acceleration, velocity and displacement measurement
3. Different vibration frequency selection
4. High sensitivity probe for accurate measurement
5. Provides long and short probe head ,each one is suitable for different situation measurement.
6. Equipped with AC signal output interface
7. Low power indication function
8. Auto power-off function
9. LCD backlight
10. Simple to use, the structure is compact, portable for
11. carrying along with measurement
Specifications：
Measuring mode
piezoceramic accelerometer
Acceleration measurement range
0.1~199.9m/s2
Speed measuring range
0.1~199.9m/s
Displacement measurement range
0.001~1.999mm
Acceleration measurement frequency
10HZ~1KHZ(LO)
1KHZ~15KHZ(HI)
Speed measuring frequency
10HZ~1KHZ
Displacement measuring frequency
10HZ~1KHZ
observational error
±5%H±2digits
AC Output
AC output Peak (display full range)
MAX
---
temperature measurement
---
unit conversion
---
packing specification
Power Supply
9VDC battery
Net Weight
147g
Product size
184*67*30mm
Packing
Color box
Standard carton capacity
40PCS
Standard carton size
52.0*40.0*49.0cm
Standard carton gross weight
12.5KG
