Features

 1. Small size, easy to carry, can be used for single hand;  Compact structure, built-in WIFI, hot spot, azimuth, roll Angle, and other groups of sensors.

2. Startup time is less than 5s, super long standby up to 7 hours, stable and reliable performance, can work day and night without difference, strong anti-fall and earthquake resistance, suitable for harsh monitoring environment.

3. Can be one button to take photos and video, easy to capture monitoring details;  64 GB (up to 256 GB) of storage space for information transfer and evidence collection.

4. The product adopts no block design, unique image processing algorithm, obvious noise reduction effect, unique digital enhancement algorithm and picture-in-picture amplification and automatic image stretching algorithm.

5. 1024×768 ultra high resolution OLED eyepiece system, 50Hz real-time imaging, fast movement without drag.  Professional telephoto germanium lens imaging 1-8 times continuous zoom, detection distance, a wider range.  White heat/black heat/brown/iron red/rainbow color options, brightness and gain can be adjusted (easier to find the target in extremely harsh environment).

6. The infrared lens adopts aspheric technology to improve the optical performance while reducing the weight and optical length of the lens. At the same time, the unique center calibration method is adopted to ensure that the optics can image clearly at different distances and temperatures for different targets

7. Optical materials are made of unconventional materials with strong reliability and stability;  The lens is coated with infrared antireflective film and waterproof film for easy wiping and protection.  The exterior uses ABS material as the main material of structural design.

 Specification

 ▶ Working band：8 ~ 14μm

▶ Detector Specifications：384× 288/640 ×480 (17μm / 12μm)

▶ Image frame frequency：25Hz (384) / 50Hz(640)

▶ Lens parameter：50mm F=1.0

▶ Electronic amplification：1~8X

▶ Magnification modes：ordinary magnification and picture-in-picture magnification.

▶ Hotspot Tracking：support

▶ Image enhancement：support

▶ False color mode：supports 9 false color modes, such as white/black/brown/iron red/rainbow

▶ Crosshair：5 types of crosshair

▶ Detection range：1000m (typical weather conditions) / 2500m (typical weather conditions)

▶ Identification distance：280m (typical weather) / 600m (typical weather)

Parameters of the eyepiece

▶ Display：0.5 inch OLED display, 1024×768 resolution

▶ Exit pupil distance：35mm

▶ Eyepiece magnification：12X

Image storage

▶ Playback：supports one-click camera and video playback, and video and pictures can be played back on the machine.

▶ Image resolution：1024x768

▶ Storage：64 GB (optional 128 GB /256 GB)

Interface specification

▶ Video output：Micro HDMI

▶ Transmission：WIFI/hot spots

Built-in Laser rangefinder

▶ The range is 1000 meters

▶ Ranging wavelength pulse 905nm

▶ Ranging frequency 25-35khz adaptive

▶ Ranging accuracy ±1m

Data sensor

▶ Impact recording：Supports automatic impact recording, which automatically prerecords and saves videos before and after impact. The duration and sensitivity of impact video can be adjusted.

▶ One-click gun calibration：support

▶ Azimuth sensor：static accuracy 0.05° dynamic 0.1°

▶ Acceleration sensor：2G-60g internal adjustable

▶ Rolling Angle sensor：range ±90° Static accuracy 0.05° dynamic 0.1°

▶ Pitch sensor：range ±90° Static accuracy 0.05° dynamic 0.1°

▶ Height sensor：support (optional)

Physical properties

▶ Waterproof seal：IP66 (airtight)

▶ Operating temperature：-40℃ ~ +60℃

▶ Storage temperature：-45℃ ~ +65℃

▶ Input voltage：DC5V

▶ Battery：26500A

▶ Working time ：>7 hours

▶ Product size：255×105×83 (mm)

▶ Product weight：≤1.2g
