Features:
1. 60000 count
2. 4~5 times/s sampling rate
3. 4~20mA loop percentage measurement
4. AC+DC measurement
5. VFC low-pass filtering
6. LoZ low impedance input
7. OLED display
8. MAX/MIN/AVG modes
9. Peaks hold
10. Analog bar: more intuitive, faster observation of dynamic signals
11. Li-ion battery; 200h battery life
12. USB/Bluetooth communication
13. 9999 data storage
Specifications:
Specifications
Range
Best Accuracy
Model
UT171C
DC Voltage (V)
600mV/6V/60V/600V/1000V
±(0.025%+5)
AC Voltage(V)
600mV/6V/60V/600V/750V
±(0.4%+40)
DC current (A)
600uA/600OuA60mA/600mA6A/10A
±(0.15%+2)
AC Current(A)
600uA/6000uA60mA600mA6A/10A
±(0.75%+5)
Resistance (Ω)
600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ
±(0.05%+2)
Admittance (nS)
60nS
±(1.0%+10)
Capacitance(F)
6nF/60nF/600nF/6uF/60pF/600uF/6mF/60mF
±(2.5%+40)
Frequence (Hz)
10Hz~10MHz
±(0.01%+5)
lemperature (°C)
-40°C~1000°C
±(1.0%+30)
lemperature (°F)
-40°F~1832°F
±(1.5%+50)
Features
Display Count
60000
Auto/Manual Range
√
True RMS
√
Bandwidth (Hz)
100KHz
√
AC + DC
√
V.F.C
√
4~20mA Loop
0~100%
√
LoZ(ACV)
Around 3KΩ
√
Continuity Buzzer
√
Duty Cycle
1%~99%
√
Square Wave Output
√
NCV
√
Data Hold/MAX/MIN
√
Relative Mode
√
Peak Hold
√
Data Storage
9999
Date Time Display
√
Data Comparsion Function
√
USB Interface
√
Display Type
OLED
LCD Backlight
√
Analogue Bar Graph
√
Mis-plug Alarm
√
Low Battery Indication
√
Rechargeable Battery
√
Auto Power Off
Around 15 Minutes
√
Input Protection
√
Input Impedance for DCV
Around 1GΩ
√
General Characteristic
Power
7.4V 2000mAh Li-ion Battery
LCD Size
70.6mm x35.3 mm
Product Color
Red and Grey
Product Net Weight
384g
Product Size
206mm x 95mm x 55mm
Standard Accessories
atteries,Test lead,Point Contact Temperature Probe,USB Interface Cable,Power
Adaptor(For UT171B/C),PC Software CD
Standard Individual Packing
Gift Box,Carrying Bag,English Manual
Standard Quantity Per Carton
20 PCs
Standard Carton Measurement
530mm x 360mm x 285mm (0.055 CBM Per Standard Carton)
Standard Carton Gross Weight
22 Kg
Optional Accessories
Bluetooth Adaptor(UT-D07)
The UT171C within Li-ion Battery,we only ship it to you by AliExpress Standard Shipping or Singapore post or EMS or DHL
