1. Measuring medium: gas, liquid, steam
2. Connection mode: flange card mounting type, flange type, plug-in type
3. Caliber specifications: flange card-mounted caliber selection 25,32,50,80,100
4. Flange connection type caliber selection 100,150,200
6. Measurement accuracy 1.0 grade 1.5 grade
7. The temperature of the measured medium: normal temperature -25℃100℃, high temperature -25℃150℃ -25℃250℃
8. Output signal Pulse voltage output signal High level 810V Low level 0.71.3V
9. The pulse duty cycle is about 50%, and the transmission distance is 100m
10. Pulse current remote transmission signal 420 mA, transmission distance is 1000m
11. The use environment of the instrument Temperature: -25℃+55℃ Humidity: 590% RH50℃
12. Material stainless steel, aluminum alloy
13. Power supply DC24V or lithium battery 3.6V
14. Explosion-proof grade Intrinsically safe type iaIIbT3-T6, protection grade IP65.
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
