Easy Assembly - terminate in field in minutes without special tools
Wire Connection: Stranded wire AWG 27/7 to 22/7, wire diameter from 0.46 to 0.76 mm
Wire Connection: Solid wire AWG 26/1 to 22/1, wire diameter from 0.4 to 0.76 mm
Transmission Characteristics: Cat7 per IS0/IEC 11801 Ed.2.2:2011-06
Complies with class Ea to ISO/EIC 11801 Ed.2.2.2011-06, DIN EN 50173-1:2011-09 10 Gbit
Color: Gray
Material: plastic, metal
IEEE 802.3an
Supports Power over Ethernet (PoE, PoE plus, and UPoE)
Compatible with Cable Jacket Diameters from 6 to 9.5 mm
Adjustable Strain Relief (6mm to 9.5mm Cable outside diameter)
Load Bar for Faster and Easier Wire Pattern Termination
Operating temperature: -40 ~ +60°C
Relative humidity: 85% (+30°C), Air pressure: 70-106Kpa
Gold Plated Bronze Blade: bronze and gold plating (3-50 µinch}, mating durability not less than 750 cycles
Intermediate resistance: no more than 20 megohm in normal atmospheric pressure (not including bulk resistor)
Insulated resistance: no less than 1,000 megohm in normal atmospheric pressure
1,000 VDC (700 VAC)
Retention strength: 7.7kg between jack and plug
Package Contents:
10pcs * Cat7 connector
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
