Built in change mode, you can adjust by dialing code
DMX512 address code can be set via DIP
3 relay outputs,5A per channel
Working voltage: DC12V-24V
Relay load: 5A per channel
Controller: DMX512 3P D
mx512 Data: 0-127 Relay Switch OFF,128-255 Relay Switch ON
Size: 120*55*20mm
color: blue
material: plastic
DIP10 function key (FUN).
DIP10 (FUN) is OFF, as DMX512 mode, receive standard DMX512 signal. Occupies three address code, (R, G, B for each channel), DIP1-DIP9 address code setting.
When less than 127 DMX512 data relay off
DMX512 data is greater than 127 when the relay is closed
DIP10 (FUN) is ON, the built-in change mode and does not receive standard DMX512 signal. DIP1-DIP9 to invoke the built-in effects settings.
Package Contents: 1 x Relay Switch
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
