4'' SAA-2N NanoVNA V2 3GHz 2.2 Network Analyzer HF VHF UHF Antenna Analyzer

Name: 4'' SAA-2N NanoVNA V2 3GHz 2.2 Network Analyzer HF VHF UHF Antenna Analyzer
Brand: mickcara
SKU: 8456712615742
Price: 163.94 USD
Availability: InStock

2 sold in last 8 hours

Brand: mickcara

Product Code: 8456712615742

Availability: In stock

🔥BUY 3 GET 4th 50% OFF 🔥 CODE:MK50
🔥BUY 2 GET 3rd 35% OFF🔥 CODE: MK35
🔥BUY 1 GET 2nd 35% OFF🔥 CODE: MK20

$163.94

Quantity:

Subtotal: $163.94

283 customers are viewing this product

Tags:

Description

Introduction S-A-A-2 designed by OwOComm, a portable vector network analyzer up to 3GHz. We strictly follow OwOComm's documentation and use 0.5ppm TCXO to ensure high frequency measurement accuracy. The complete metal shell can fully protect the internal precision circuit and the protection of the external interface is fully considered. The customized high-performance SS405 cable provides good stability. Phase stabilization performance, high-performance calibration kit to ensure that the calibration SWR is less than 1.03 up to 3GHz Product performance: Frequency range: 50kHz-3GHz Frequency error: <2ppm Frequency temperature: <0.5ppm System dynamic range (calibration): 70dB (up to 1.5GHz), 60dB (up to 3GHz) S11 noise floor (calibration): -50dB (up to 1.5GHz), -40dB (up to 3GHz) Scanning speed: 100 points/sec Display: SAA2 2.8 inches, 320 x 240; SAA2N 3.95 inches, 320 x 480 RF port: SAA2 SMA; SAA2N N (If you need to measure anti-pin SMA devices such as Wi-Fi antenna, please use SMA to RPSMA connector) USB interface: microUSB Power supply: USB, maximum charging current 1A Battery: SAA2 2000mAh lithium ion; SAA2N 3000mAh lithium ion Battery connector: JST-XH 2.54mm Maximum scanning point (on the device screen): 201 Maximum scanning point (USB): 1024 Port 2 return loss (1.5GHz): 20dB typ Port 2 return loss (3GHz): 13dB MIN VNA-QT software compatible system: Linux, Windows (7+), Mac OS planned Packing list SAA-2N host (built-in 3000mAh battery) x 1 USB data cable x1 50cm N male to male RG142-PUR RF cable x2 NSimple calibration kit OPEN *1 N simple calibration kit SHORT *1 N simple calibration kit LOAD *1 N female to female connector *1 EVA carrying case *1 Lanyard touch paddle *1

Logistics information

Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
