5A 80W CNC DC-DC Buck Boost Converter 6V 12V 24V 36V Power Module CC CV 0.6-36V Adjustable Regulated Laboratory Power Supply
Features:
1. Use high-quality materials, durable
2. CNC DC buck-boost power supply
3. Large screen display, full-view dedicated power LCD, various statuses at a glance
4. One-piece matte panel, high-quality aluminum alloy knob cap, good hand feeling
5. Wide range of applications
Specifications:
SK35H:
Input voltage: 5.0~30V
Output current: 0~4.0A
Output power: 35W
Output voltage: 0.6~30V
SK80H:
Input voltage: 6.0~36V
Output current: 0~5.0A
Output power: 80W
Output voltage: 0.6~36V
Voltage resolution: 0.01V
Conversion efficiency: about 88%.
Voltage accuracy: ±0.5% + 1 word
Current accuracy: ±0.5% + 3 words
Current resolution: 0.001A
Soft start: Yes
Input anti-reverse connection: Yes
Output anti-backfilling: Yes
Input Undervoltage Protection: (4.7-30V adjustable, default 4.7V)
Output Overvoltage Protection: (0-37V adjustable, default 37V)
Output Overcurrent Protection: (0 -5.2A adjustable, default 5.2A)
Output over power protection: (0 -82W adjustable, default 82W)
Over-temperature protection: Yes, default 100°C
Timeout protection: (0-100H adjustable, off by default)
Overcapacity protection: (0~9999AH adjustable, off by default)
Super energy protection: (0~9999WH adjustable, off by default)
A wealth of input interfaces has been added, but two or more interfaces are prohibited from being accessed at the same time
The front of the shell has an invisible air inlet, and the reasonable outlet air dissipation structure can effectively take away the heat inside the shell and make the power supply operate efficiently and reliably
Package Included:
Adjustable regulated power supply*1
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
