Product name: ASMC-04A Super Torque Digital Servo
Working voltage: 12V to 24V (DC) (this means that any voltage between 12V or 24V can be used)
No-load rotating current: less than 500mA
Maximum torque: 110kg.cm (24V) (actual measurement, not theoretically calculated value)
1078N.cm(24V) (actual measurement, not theoretically calculated value)
55kg.cm(12V) (actual measurement, not theoretical calculation value)
539N.cm(12V) (actual measurement, not theoretical calculation value)
Angular speed: 0.12s/60°(0.12s is required to turn 60 degrees), at 24V;
0.24s/60°(0.24s is required for 60°rotation), at 12V;
Rotation angle: 300°MAX, which means the maximum stroke is 300° (0 to 300° electronic limit is adjustable)
Input mode: pulse signal (remote control, multi-channel steering gear controller, single-chip microcomputer) or analog voltage signal (potentiometer)
Pulse signal input range: 0.5ms-2.5ms suitable for all "multi-channel steering gear controllers", "1ms-2ms model airplane remote control", "MCU programming", "Arduino", etc.;
Voltage signal input range: 0V to +5V
Control accuracy: 0.32°
colour: blue
Material: PCB+metal
Size: 95.5x60.5x102.6mm
Package Contents:
1 x ASME-04A Servo
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
