AR63B Smart Sensor Vibration Meter Digital Precision Tester Analyzer Vibrometer Velocity Acceleration Displacement measurement
FEATURES
Vibration meter(also called vibration severity) uses Piezoelectric Acceleration Transducer transfer the vibration signal in to electrical signal, analyze the input signals, and show the Acceleration, speed, shift of the vibration. It is widely used in the lines of Power, petrochemical, machinery manufacturing, metallurgy, vehicles, etc.
SPECIFICATIONS
Measuring Principle
Piezoelectric Ceramic Accelerometer
(shear-type)
Acceleration Range
0.1~199.9m/s2
Velocity Range
0.1~199.9mm/s
Displacement Range
0.001~1.999mm
Acceleration Frequency
Range
10Hz~1KHz (LO)
1KHz~15KHz (HI)
Velocity Frequency Range
10Hz~1KHz
Displacement Frequency
Range
10Hz~1KHz
Accuracy
plusmn5%H plusmn2 digits
Signal Output
AC output 2V peak ( Display full scale )
Max Hold Function
radic
Temperature
Measurement
radic
℃/℉Selection
radic
PACKING INFORMATION
Power
9V Battery(not included in package)
Product Net Weight
137g
Product Size
150*70*30mm
Packing Style
Aluminum Box
Standard Quantity Per
Carton
12PCS
Standard Carton Size
45*32.5*52cm
Standard Carton GrossWeight
14.14kg
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
