Description:

 300° horizontal rotation without limit, vertical 0°～90° automatic flip

 4 white light + 4 infrared light design, bright white light when an object is moving, it can illuminate or scare intruders

 Rotation speed 0.01°—30°/S

 Continuously variable speed, continuous 300° horizontal rotation, vertical 90° automatic flip

 Proportional zoom function, automatically match the rotation speed according to the zoom size;

 Adopting high-performance 32-bit ARM design, stable performance, internal setting data will not be lost after power failure

 Baud rate 9600bps

 Support automatic tracking function

 IP66 waterproof rating, can be used outdoors

 Support onvif protocol

 Specification:

 System:

 Main processor: industrial-grade embedded microcontroller

 Operating system: embedded LINUX operating system

 Video:

 Image sensor: 2 million pixel CMOS

 Image coding standard: H.264

 Monitoring image quality: 1920*1080/1280*720

 Video quality: 1920*1080/1280*720

 Image motion detection: support

 Capturing function: support

 Video flip: support

 Audio:

 Coding standard: G.711

 Audio input: support

 Audio output: support

 Video management

 Recording method: manual recording, timing recording, alarm recording

 Video saving: TF card\cloud storage

 Remote playback: support

 Alarm trigger: speaker alarm, alarm recording, sending email

 Network: Wireless network 802.11b/g/n

 Stream: Two stream

 Network protocol: support TCP/IP, RTSP

 Transmission mode: Smart P2P

 WIFI networking: 2.4G WiFi/AP direct connection

 Expand:

 IR-CUT: automatic switching

 TF card: maximum support 128GB TF card (the product does not include a memory card)

 WIFI support

 433MHz alarm: not supported

 Power supply: power supply DC12V power consumption 24W

 surroundings:

 Working temperature: 0℃－＋55℃

 Working humidity: 10%-50%

 Lens: 3.6MM

 Light board: 4 infrared lights + 4 white lights

 Camera size: (mm) 90mm*140mm*90mm

 Camera weight (g): 390g

 Note:

 -There might be little error of size for manual measurement.

 -Due to different lighting effects and monitor settings, the actual item's color may not exactly reflect the color on pictures.

 Packing list  Package includes:

 1 * Camera

 1 * Network waterproof package

 1 * 12V2A power adapter

 1 * screw pack

 1 * Instruction
