PCM 44.1K ~ 384K 32BIT
DSD DSD64, DSD128, DSD256
(The AK4493SEQ chip itself supports hard decoding of DSD512, but in actual use, the PCM/DSD switches automatically. It is easy to achieve better switching effect when the board supports below DSD256 without additional auxiliary signals)
Output:
- RCA single-end output: 2.1Vrms/- 0dB
- XRL balanced output: 4.2Vrms/- 0dB
- XLR interface definition: 1-GND; 2-Positive; 3-Negative
Power Supply:
- Digital power supply: DC stabilized voltage: +5V, voltage range: ± 5%
- Analog power supply: DC stabilized voltage: ±12 ~ 15V (analog power supply is only suitable for ±15V)
Size:
- L x W (excluding protruding part): 100mm × 100mm
IIS Input Interface Function and Description:
- DA: DATA/DSD_R; PCM data input/DSD right channel data input
- BC: BCK/DSD_BCK; PCM digit clock input/DSD clock signal input
- LR: LRCK/DSD_L; PCM channel clock input/DSD left channel data input
- MC: MCLK; PCM main clock input
- DE: DSD_ON; DSD input, DSD_ON=1: input DSD; DSD_ON=0: input PCM
- MU: MUTE; mute input, MUTE=1: mute; MUTE=0: normal playback status
