Functions and features:
215mm wheelbase
Built-in OSD Betaflight
Support BLHeliSuit configuration
Support voltage3-4S
7-10minutes of battery life
Remote control distance (about 400meters with FLYSKY remote control) (about2000meters with T-PRO remote control)
Propeller:
Model: 5043
Pitch: 4.3 inches
Material: PC
Weight/G: 4.63G
Inner diameter of center hole: 5mm
Propeller diameter: 13.5mm
Center thickness: 7mm
ESC:
Working voltage: 2-6S
Maximum continuous working current: 45A
Maximum instantaneous working current: 50A
Support communication modes: DShot150/300/600, PWM, Oneshot125, Oneshot42 and Multshot
Firmware version: BL16.7
Installation hole distance: 20 * 20mm / 30.5 * 30.5mm
Product size: 44 * 44 * 5.5
VTX:
Weight: 12g
Input voltage range: 7-24V
Frequency: 48CH
Output power: 0mW / 25mW / 100mW / 200mW / 400mW / 600mW switchable
Transmission distance: ≥0.5km25mW, ≥1km200mW, ≥2km600mW
Installation size: 30.5*30.5mm
2205 Motor or 2306 Motor:
2205 Motor
Size: 2205
Stator diameter: 22 mm
Stator height: 5 mm
Motor KV: 2300
Weight: 29g
Support voltage: 3~4S
2306 Motor
Stator diameter: 23 mm
Stator thickness: 6 mm
Number of stator arms: 12 pieces
Number of stator poles: 14
Motor KV: 2400
Maximum continuous power: 750 watts
Weight: 32 grams
Outer diameter: 28 mm
Support voltage: 3~4S
Flight controller:
Name: F4 V2
Size: 36x36mm
Mounting hole: 30.5x30.5mm
STM32 F405 MCU can shorten the cycle time.
Support SBUS / PPM / IBUS receiver mode
Built-in power module BEC
Razer camera or ratel 2 camera:
razer camera
Sensor: CMOS 1/3
Lens: 1.8mm
Video format: PAL/NTSC switchable
Resolution: 1200TVL
Input voltage: DC4.5V-25V
Weight: 4.5g
Size: 19*18.7mm(W*L)
White balance: automatic
WDR: 90db
Caddx ratel 2 camera
Sensor: CMOS 1/1.8
Lens: 2.1mm
Video format: PAL/NTSC switchable
Resolution: 1200TVL
Input voltage: 5V-40V
Weight: 5.9g
Size: 19*19*20mm
White balance: automatic
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
