Model |
ER-Q2 |
|
Dimension |
90*120*50mm |
|
Print method |
Line thermal printer |
|
Paper width |
58mm |
|
print width |
58mm |
|
Weight ( g) |
235 (not including the paper roll) |
|
Max diameter of paper roll |
60mm |
|
Dot per lie |
384 dots/line |
|
internal characters |
ASCII CH(8x16,9x17,9x24,12×24); GB18030(16x16,24×24) |
|
Print speed |
50~80mm/s |
|
Life cycle time |
100km(printing density under 12.5%)/100 million pulses |
|
text and graphic Support |
English, figure, symbol, Chinese, graph, curve, icon pre-stored, barcode(CODE39EAN13EAN8 CODABARCODE128CODE93ITF) QR code ,PDF417 |
|
Dot pitch (resolution) |
203DPI/8 dots/mm |
|
interface |
Mini USB, Wifi |
|
Power |
5000mAh 7.4V rechargeable Lithium battery |
|
Recharge adapter |
Stand by recharging / AC adapter |
|
Self-check |
Without paper / cover open |
|
Black mark test |
Supported |
|
Paper feeding |
Easy paper loading |
|
commands |
ESC/POS compatible with order sets |
|
Paper cut |
By hands |
|
operate setting |
Temperature -10°C~50°C ; Humidity 20%~85% |
|
Recharge Setting |
Temperature 5°C~40°C; Humidity 20%~85% |
|
Storage Setting |
Temperature -20°C~70°C ; Humidity 5%~95% |
|
Standard accessories |
Long-term preservable paper,AC adapter,li-ion battery,USB cable |
|
Optional accessories |
Serial interface cable/leather coat/CD |
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
