Features : The ESP-07 module is one of the most complete of the ESP family as it allows you to use biggest amount of pins. This cheap and small Wifi transciever is the perfect solution for home Automation and IoT applications. It can be the replacement for your NRF24L01, it can talk to your Wifi router directly through the UART MCU's. The system is equipped with ESP8266 and it's features are: energy saving VoIP can quickly switch between the sleep / wake patterns, with low-power operation adaptive radio bias, front-end signal processing functions.  Descriptions: 1.Support 802.11 b/g/n standard  2.Built-in Tensilica L106 low power consumption 32 bit MCU,primary frequency supports 80 MHz and 160 MHz,support RTOS 3.Built-in 10 bit high-precision ADC  4.Built-in TCP/IP protocol stack 5.Built-in TR switch,balun,LNA,power amplifier and matching network 6.Built-in PLL,AVR and power management component,802.11b mode +20dBm output power 7.A-MPDU,A-MSDU polymerization and 0.4s guard interval  8.WiFi 2.4 GHz,support WPA/WPA2 security mode  9.Support AT remote upgrade and cloud OTA upgrade  10.Support STA/AP/STA+AP operating mode  11.Support Smart Config function (include Android and iOS device) 12.HSPI,UART,I2C,I2S,IR Remote Control,PWM,GPIO 13.Deep sleep holding current is 10uA,power off current is less than 5uA 14.Within 2ms awakening,connect and transfer data package  15.Standby state power consumption is less than 1.0 mW (DTIM3)  Specification: Color:multicolor Size:24X30MM Model: ESP8266  Standards Certification: FCC / CE / TELEC Wireless standards: 802.11 b / g / n Operating temperature: -40 ° ~ 125 ° Storage temperature: Nomal temperature  Package Included: 1*ESP8266 ESP-07S Wireless Transceiver Module   Notes: 1.Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures. 2.Due to the manual measurement and different measurement methods, please allow 1-3cm deviation. Thanks! Features : The ESP-07 module is one of the most complete of the ESP family as it allows you to use biggest amount of pins. This cheap and small Wifi transciever is the perfect solution for home Automation and IoT applications. It can be the replacement for your NRF24L01, it can talk to your Wifi router directly through the UART MCU's. The system is equipped with ESP8266 and it's features are: energy saving VoIP can quickly switch between the sleep / wake patterns, with low-power operation adaptive radio bias, front-end signal processing functions.  Descriptions: 1.Support 802.11 b/g/n standard  2.Built-in Tensilica L106 low power consumption 32 bit MCU,primary frequency supports 80 MHz and 160 MHz,support RTOS 3.Built-in 10 bit high-precision ADC  4.Built-in TCP/IP protocol stack 5.Built-in TR switch,balun,LNA,power amplifier and matching network 6.Built-in PLL,AVR and power management component,802.11b mode +20dBm output power 7.A-MPDU,A-MSDU polymerization and 0.4s guard interval  8.WiFi 2.4 GHz,support WPA/WPA2 security mode  9.Support AT remote upgrade and cloud OTA upgrade  10.Support STA/AP/STA+AP operating mode  11.Support Smart Config function (include Android and iOS device) 12.HSPI,UART,I2C,I2S,IR Remote Control,PWM,GPIO 13.Deep sleep holding current is 10uA,power off current is less than 5uA 14.Within 2ms awakening,connect and transfer data package  15.Standby state power consumption is less than 1.0 mW (DTIM3)  Specification: Color:multicolor Size:24X30MM Model: ESP8266  Standards Certification: FCC / CE / TELEC Wireless standards: 802.11 b / g / n Operating temperature: -40 ° ~ 125 ° Storage temperature: Nomal temperature  Package Included: 1*ESP8266 ESP-07S Wireless Transceiver Module   Notes: 1.Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures. 2.Due to the manual measurement and different measurement methods, please allow 1-3cm deviation. Thanks! Features : The ESP-07 module is one of the most complete of the ESP family as it allows you to use biggest amount of pins. This cheap and small Wifi transciever is the perfect solution for home Automation and IoT applications. It can be the replacement for your NRF24L01, it can talk to your Wifi router directly through the UART MCU's. The system is equipped with ESP8266 and it's features are: energy saving VoIP can quickly switch between the sleep / wake patterns, with low-power operation adaptive radio bias, front-end signal processing functions.  Descriptions: 1.Support 802.11 b/g/n standard  2.Built-in Tensilica L106 low power consumption 32 bit MCU,primary frequency supports 80 MHz and 160 MHz,support RTOS 3.Built-in 10 bit high-precision ADC  4.Built-in TCP/IP protocol stack 5.Built-in TR switch,balun,LNA,power amplifier and matching network 6.Built-in PLL,AVR and power management component,802.11b mode +20dBm output power 7.A-MPDU,A-MSDU polymerization and 0.4s guard interval  8.WiFi 2.4 GHz,support WPA/WPA2 security mode  9.Support AT remote upgrade and cloud OTA upgrade  10.Support STA/AP/STA+AP operating mode  11.Support Smart Config function (include Android and iOS device) 12.HSPI,UART,I2C,I2S,IR Remote Control,PWM,GPIO 13.Deep sleep holding current is 10uA,power off current is less than 5uA 14.Within 2ms awakening,connect and transfer data package  15.Standby state power consumption is less than 1.0 mW (DTIM3)  Specification: Color:multicolor Size:24X30MM Model: ESP8266  Standards Certification: FCC / CE / TELEC Wireless standards: 802.11 b / g / n Operating temperature: -40 ° ~ 125 ° Storage temperature: Nomal temperature  Package Included: 1*ESP8266 ESP-07S Wireless Transceiver Module   Notes: 1.Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures. 2.Due to the manual measurement and different measurement methods, please allow 1-3cm deviation. Thanks!
