Nickeled Hot Water Flow Valve BSP G1/2" 100 Celsius Water Turbine Meter 12V 1-30L/min Flow Meter Water Sensor iSentrol
Hall effect Water Brass Flow sensor
Flow Sensor Product description:
(1)Product name :Brass flow sensor
(2)material : Brass Flow Sensor
(3)size : 65*35*30mm
(4) Thread Connection: G1/2 "
(5):Mounting Position: Horizontal & Vertical
(6)Color: Brass Nickeled
(7)Place of Orign : China(Mainland)
(8) Brand : iSentrol
(9)Item No.: ISX-21
(10) Application: Water heater, broiler and heat pump ...etc.
2.Flow Sensor Technical Data
(1) Flow Rate: 1~30L/min
(2)Flow Pulse: F= 7.5 *Q ± 5% , Q=L/min
(3) Working Voltage:DC12V for sensor and valve
(4) Working Current: 15mA
(5) Suffering Pressure: Max 1.5Mpa
(6) Working Temperature: -40 °C ~+100 °C,
(7)Min Insulation Resistance:100M Ohm
(8)Output Pulse Duty Cycle: 50% +/- 10%
(9) Max output Pulse Voltage: >DC4.7V ( input voltage DC5V)
(10)Min Output Pulse Voltage :<DC0.5V ( input voltage DC5V)
(11) Sensor : Hall effect sensor, Digital Output.
(12) wire connection :
Terminal 1 ( Red) : Vdd " + "
Terminal 2 (Black) Vout " - "
Terminal 3 ( Yellow ) Gnd : output
(13) Connector : Housing SM2.54-3P
