Motor
Motor Mode：GL1204 KV5000
Stator specifications：D12 * H4 0.2mm Kawasaki
Configu-ration:9N12P
Stator Diamter:12mm
Stator Length:4mm
Shaft Diameter:Φ1.5mm
Motor Dimension(Dia.*Len):Φ16.0mm*15.8mm
Magent specifications: N52H
Shift specifications: 2mm High strength steel
Bearing Specifications: d2*D5*H2.5 MR52zz Japan ISC Custom madeWinding
Specifications:180℃ ClassMultipleoxygen-freecopper
Weight(g):5.8g
No.of Cells(Lipo)：3S-4S
Flight controller
Name: Ghf412 FC F411
MCU: STM32F411C (100MHZ)
Sensor: MPU-6000 (SPI connection)/BMI270
Board size: 28.5 * 28.5MM
Power supply: 2-4S battery input (DC 7-17V)
Built-in 12A (each) Blheli_S 4 in 1 ESC Dshot600 ready
Built-in Betaflight OSD (SPI control)
Built-in 12V 2A BEC
Built-in voltage detection
Onboard 4in1 ESC Onboard 4in1 ESC MCU upgraded to EFM8BB21
Factory firmware: G_H_30_REV16_7.HEX
Defaultprotocol: DSHOT600
Powerinput: XT30
FrskyNON-EU/EU-LBTXM+ receiver Version
SBUS receiver
Frsky D8/D16 switchable
Compatible Non EU transmitter both D8 and D16 mode
Channels: 8ch or 16ch
Failsafe support
No ground interference ( Transmitter and receiver 1 m from the ground): >300m
Operating Voltage Range: 3.7~10V
Operating Current: 30mA @5V
Operating Range: Full range
With RSSI output on board: Analog 0~3.3V
Firmware upgrade-able, can be upgrade to EU-LBT with RSSI
CompatibleAC900 multimodereceiver Version
Three-in-one receiver
SBUS receiver
Frsky D16\D8\futaba s-fhss switchable
Compatible Non EU transmitter both D16 mode
Channels: 8ch or 16ch
Failsafe support
No ground interference ( Transmitter and receiver 1 m from the ground): >300m
CompatibleFrsky D8 R1MINIreceiver Version
SBUS receiver
Frsky D8Compatible Non EU transmitter both D8 mode
Channels: 8ch Failsafe support
Support receiver hardware rssi function
No ground interference ( Transmitter and receiver 1 m from the ground): >300m
CompatibleFlysky receiver Version
IBUS receiver
Protocol: AFHDS-2A
Channels: 14ch(AFHDS-2A)
No ground interference ( Transmitter and receiver 1 m from the ground): 300m
Failsafe support
Compatible
TBS NANO receiverversion
CRSF Protocol , Official TBS transmitter compatible
Protocol: CRSF
Channels: 8ch Failsafe support
Support receiver hardware rssi function No ground interference ( Transmitter and receiver 1 m from the ground): >500m
Compatible
ELRS2.4Greceiverversion
CRSF Protocol , receiver
Protocol: CRSF
Channels: 8ch Failsafe support
Support receiver hardware rssi function No ground interference ( Transmitter and receiver 1 m from the ground): >500m
PNP receiverversion
Support any bus and other protocols, users can install by themselves
5.8G VTX
Power switching: third gear(25MW 、 100MW 、200MW、400MW)
Frequency: 40CH
Input voltage: 3.3V 5.5V
Current consumption: 300mA(type)
Frequency: 5.8GHz 5bands 40 channels
Weight: 2.0g
camera
RUNCAM NANO2
1/3COMS sensor
Horizontal: 800TVL 800x600
TV system: ntsc/pal4:3
Power Input: DC 3.3-5.5vColorful：0.1Lux(F1.2)
Signal to noise ratio：> 50dB
Weight:3.3g
propeller
Gemfan D51 (2020-4) Cinewhoop props
Material: PC
Weight: 0.91g
Pitch: 2 inches
Prop diameter: 50.3 mm
Center thickness: 4.5mm
Center hole diameter: 1.5mm 3 holes
Battery recommended
Species : lipo、lipoHV
Capacity:450-750mah(850mah MAX)
Voltage:7.8-16.8v
Continuous Discharge Rate: 60C
Instantaneous discharge rate: 90C
Connector: xt30
