K3NB New Low Noise Amplifier LNA Ham Radio Module LNA 0.05-4GHZ High Lineariy
OOTDTY
Features: 100% brand new and high quality
It can be cascaded several LNA modules in order to improve gain.
It has 0.6dB typical noise factor, 19dB typical gain, 23dB P1dB.
This is a ultra low noise, high linearity, low noise amplifier module.
Used for high frequency or intermediate frequency preamplifier of radio receiver, and high sensitivity amplifying circuit of electronic detection equipment, as well as transceiver wireless communication card, tower mounted amplifier, combiner, repeaters, and distal/digital wireless broadband head equipment, etc.
Widely be used for high dynamic range receiver LNA application, and amplify small signal of 110dBM.
Specification: Voltage: 5V
Current: 90mA
Gain: 18dB AT 0.9G
Input/Output Impedance: 50Ω
Max. Output Power: P1db 22dBm(AT 2GHz)
Input Signal: <+10dBm(as low as -110dBm. If input >+10dBm, output is distorted)
Bandwidth 0.05-4GHZ(differs at different frequency, refers to S21 curve)
Noise Factor: 0.6dB AT 0.9GHz
Size:6x2.4cm/2.36x0.94inch
Package Includes: 1xRF Amplifier
note: Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
