TYPE
|
IoT handheld terminal
|
|
Processor
|
64 bit quad core ARM Cortex A53 with a main frequency of 1.5GHz
|
|
GPU
|
Mali760-MP2
|
|
storage
|
2G LPDDR2 RAM+16G EMMC ROM
|
|
OS
|
Android 5.1
|
|
display
|
5-inch HD LCD screen with a resolution of 1280 * 7205 and 3 touchable buttons
|
|
inputting method
|
Handwriting, stroke, and Pinyin input methods
|
|
frequency
|
GSM/WCDMA/FDD/TDS/TDD;
GSM quad band，TDSB34/39,WCDMA B1/2/5/8,TDD B38/39/40,FDD B1/3/7/B/20 |
|
GPS
|
Built in GPS global positioning system, supporting A-GPS; GPS+BDS, meter level positioning
|
|
interface
|
Micro USB2.0,，supporting 0TG
|
|
storage interface
|
TF card slot (Micro SD card) can support 2G-32G
|
|
bluetooth transmission
|
Bluetooth 4.0+EDR
|
|
speaker
|
Single speaker, 8 ± 15% ohm
|
|
WIFI
|
Support 802.11a/b/g/n mode，supporting WEP\WPA\WPA2-PSK\AES\WAPIPSK\802.1x EAP Encryption Protocol
|
|
Camera
|
Rear camera with 8 million pixels, front camera with 2 million pixels, rear camera with autofocus function and fill light
|
|
Battery
|
Lithium polymer batteries，4000mAh
|
|
standby time
|
one week
|
|
endurance
|
20 hours (Full functionality)
|
|
Certification/Protection
|
3C,CE/IP65
|
|
IoT functionality (RFID, barcode)
|
|
|
IoT barcode
|
1-D barcode laser scanning module, 2-D barcode scanning module
|
|
1D barcode
|
Code128,EAN-13,EAN-8,Code39,UPC-A.UPC-E,Codebar,Interleaved 2 of 5,China post 25,ISBN/ ISSN,Code93,UCC/EAN-128,GS1
Databar,HIBC,etc |
|
2D barcode
|
Honeywell/Motorola 2D barcode scanning module; Can read one-dimensional barcodes; Identification code system: QR code PDF417
Code128, EAN- 13, EAN-8, Code39, UPC-A, UPC-E, Codebar, Interleaved 2 of 5, China post 25, ISBN/ISSN Code93, UCC/EAN-128, etc |
|
IoT RFID
|
*Fully support NFC. Supports 14443A/B, 15693 protocols! Card reading distance 2cm~5cm, card reading position, battery cover
position* built-in 900M UHF RFID module, supporting reading and writing of EPCC1/G2, 18000-6C protocol cards and labels (optional)。 |
|
Working Environment
|
|
|
Working temperature
|
-25~65℃
|
|
Storage temperature
|
-30~70℃
|
|
humidity
|
0~95%
|
|
Gravity sensor
|
supporting
|
|
light induction
|
supporting
|
|
proximity sensor
|
supporting
|
|
|
supporting
|
|
Microphone
|
supporting
|
|
earphone
|
supporting
|
|
vibrator
|
supporting
|
|
|
|
|
standard configuration
|
Quad core, NFC, Bluetooth 4.0, WIF12.4G+5G, GPS+BDS, dual network dual
standby , 8 million rear cameras and 2 million front cameras |
|
optional configuration
|
1-D laser scanning module
2-D scanning module 900M ultra-high frequency RFID 900M ultra-high frequency RFID+two-dimensional scanning Electric power infrared |
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
