* Forget Ethernet cable, the NanoStation is ideal for bridging networks or sharing broadband across a distance
* To install, place the units at either end of the network and connect both to Ethernet cables - for example, connect the first unit into your modem at location one, and connect the second into an Ethernet switch or WiFi access point at the other location
* Up to 6 remote buildings can be linked over one connection with the NanoBridge supporting AP-WDS.
|
Dimensions
|
164 x 72 x 199 mm (6.46 x 2.83 x 7.83")
|
|
Weight
|
900 g (1.98 lbs)
|
|
Power Supply (PoE)
|
24V, 0.5A
|
|
Max. Power Consumption
|
6.5W
|
|
Power Method
|
Passive PoE (Pairs 4, 5+; 7, 8 Return)
|
|
Operating Frequency
|
902-928 MHz
|
|
Gain
|
8 dBi
|
|
Networking Interface
|
(1) 10/100 Ethernet Port
|
|
Processor Specs
|
Atheros MIPS 24Kc, 400 MHz
|
|
Memory
|
64 MB SDRAM, 8 MB Flash
|
|
Frequency
|
900 MHz
|
|
Cross-pol Isolation
|
28 dB Minimum
|
|
Max. VSWR
|
1.3:1
|
|
Beamwidth
|
60° (H-pol) / 60° (V-pol) / 60° (Elevation)
|
|
Polarization
|
Dual Linear
|
|
Enclosure
|
Outdoor UV Stabilized Plastic
|
|
Mounting
|
Pole-Mount (Kit Included)
|
|
RF Connector
|
External RP-SMA
|
|
Operating Temperature
|
-30 to 75° C (-22 to 167° F)
|
|
Operating Humidity
|
5 to 95% Noncondensing
|
|
Wireless Approvals
|
FCC Part 15.247, IC RS210
|
