Description:

【Compatibility】Cordless soldering station works for DEWWALT 20V/60V Flex XR Slide Style battery packs; Bossch 18/20V battery; Makiita18/20V battery; Milwauukee18/20V battery(Battery Not Included). This portable soldering station helps get your soldering job done more convenient and fast.

【Fast Heating & Adjustable Temperature】This electric HD digital soldering station heats up fast. Temperature read-outs are displayed via a digital display, effortlessly turn the adjust knob to set the temperature precisely.

【Compact & Lead-Free Solder】 compact soldering station helps save preciious work space. Lead-free soldering tip and soft handle design, provides extended comfort during long term soldering projects.

【Safe to Use】Made of high quality material, built-in low-voltage protection. With automatic cooling mode, when not in use, the handle is placed on the handle frame, the machine will cool automatically, and the temperature will rise rapidly when picked up.

【Condition】Support with T12 handle heating core, with DC port 24V auxiliary power supply

Specification:

* Power: 70W max

* Work Voltage: 12-24V

* MCU: 32bit M1

* Screen: 1.77inch TFT

* Condition：100% full new

* Weight: about 0.33kg

* Size：22.00cm*11.20cm*6.10cm

* Color：as photos show

* Compatible：For Dewwalt/ Bossch/ Milwauuke/ Makiita 18/20V battery

* Advantage：Cordless, easy to carry.

* Temperature unit: Celsius/Fahrenheit Celsius

Basic operation:

1. In the normal mode, briefly press the encoder to enter the preset temperature mode (four groups of common temperatures are preset according to your own needs, and the rotary encoder can cycle through these four groups of preset temperatures), and then briefly press again to enter the set temperature mode. Each time you rotate the encoder, the temperature increases by 10 degrees, and the step temperature is adjustable!

2. In the normal mode, long press the encoder to enter the setting menu, short press to select, short press again to cancel the selection, and long press the encoder in the menu interface to exit and return to the previous level!

Important notes for T12 welding station:

- If you enter the menu to change the parameters or restore the factory settings, be sure to pay attention to the following parameters to be set correctly, otherwise there will be errors and other abnormalities!

1. The sleep time must be set to "0", otherwise the sleep seat function will become invalid. (Time setting in main menu → Sleep time → Set to 0

2. The standby time is set to 10 (time setting in the main menu → standby time → set to 5 or 10, and you can set any length of time according to your needs)

3. Under voltage protection is set to 15 or 16 (other settings in the main menu → voltage protection → set to 16)

4. Sleep temperature setting (temperature setting in main menu → sleep temperature → set to 60)

5. Maximum temperature setting (temperature setting in main menu → maximum temperature → 420)

6. If you use T12 heating element, please select T12 as the heating element model (main menu → other settings → nozzle selection → T12)

Package Included:

1 x Soldering station(the battery is not included)

1 x T12-K handle with heating element
