Features:
0.1dB resolution
Volume stalls from 30 to 130dB
Maximum lock function
A, C, Z frequency weighted
A, C, Z peak lock function
Fast, Slow and Impulse time weighted
AC/DC output signal
Can be fixed on the tripod
Specification:
Applicable Standards：IEC 61672-1 Class 2, ANSI S1.4 Type 2
Digital Display：4-digit LCD
Measurement Range:30-90dB, 45-110dB, 65-130dB
Resolution:0.1dB
Typical Instrument Frequency Range:31.5Hz to 8KHz
Accuracy：± 1.4dB (ref 94dB @ 1KHz)
Dynamic Range：65dB
Frequency Weighting:A, C and Z
Time Weighting:F (Fast), S (Slow), and I (Impulse)
Microphone:1 / 2-inch pre-polarized condenser microphone
Analog output
AC output:1.0Vrms corresponding to each rang step, Impedance ≒ 5KΩ
DC output:10mV / dB(nominally), Impedance ≒ 5KΩ
Auto data memory:microSD CARD 4GB (1151)
Operating Temperature and Humidity;-10 ° C to + 50 ° C, 30% to 90% RH non-condensing
Storage Temperature and Humidity：-10 ℃ to + 60 ℃, <70% RH non-condensing
Power Supply:One 006P 9V or IEC 6F22 or NEDA 1604 Battery（Not Included Package）
Battery Life:About 24 hours
Dimensions:246 (L) × 64 (W) × 26 (D) mm
Weight:180g
Accessories:Manual, carrying case, 3.5f headphone head, adjustment screwdriver, windshield, CD software disc, micro-USB cable
Optional Accessories:AC adaptor DC9V
