Applications:
Used for measuring thickness and corrosion of pressure
vessels, chemical equipment, boilers, oil storage tanks,
etc. in industries of petroleum, shipbuilding, power
station, and machine manufacturing. Applicable to
measure the thickness of many materials, e.g. Steel, Cast
iron, Aluminum, Red copper, Brass, Zinc, Quartz glass,
Polyethylene, PVC, Gray cast iron, Nodular cast iron.
Features:
* Using the latest high performance and low power consumption microprocessor technology.
* Bidirectional measurement, for materials within measurement range, thickness is measurable with know velocity, Conversely velocity is measurable with know thickness.
* Automatic memory material code and sound velocity value, convenient to use.
* Coupling symbol indication.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Specifications：
Housing Material
Aluminum Alloy
Display
Large Screen LCD
Measuring Range
0.75~400mm(45#steel,Depend on Probe)
Resolution
0.1mm/0.1mm/0.001 inch
Accuracy
±(0.5%n+0.05)
Sound Velocity
500~9,990m/s
Lower Limit of Pipes
Φ15x2.0mmΦ20x3.0mm Determined By Transducer
Operating Conditions
Temperature
0~40ºC
Humidity
<85%RH
Power Supply
2x1.5V AA(UM-3)Battery
Dimensions
130x76x32 mm
Weight
340g(Not Including Batteries)
Material Selection:
Code
Material
CD01
Steel
CD02
Cast Iron
CD03
Aluminum
CD04
Red Copper
CD05
Brass
CD06
Zinc
CD07
Quartz Glass
CD08
Polyethylene
CD09
PVC
CD10
Gray Cast Iron
CD11
Nodular Cast Iron
XXXX
Sound Velocity
Difference between TM-8816, TM-8816C and TM-8818:
