Specification:
Origin: Mainland China
Firmware update and download software:
https://drive.google.com/drive/folders/1_GB26bcqH1VJ-S3skzg38d46CwsZmee7
Note:
In M-4 mode, due to the power change during tuning, the power output cannot meet the power detection requirements of the fast switching mode, so if you use a tuned antenna, please use the standard switching mode. In 4-M mode, it has no effect.
Parameters:
Voltage and current: DC 9-15V maximum 100mA
Frequency range: DC-60MHz
Power tolerance: maximum 200W
Interface type: UHF SL16
Applicable impedance: 50Ω
Insertion attenuation: DC-30MHz: ≤0.1dB; 31-60MHz: ≤0.3dB
Insertion SWR: DC-30MHz: ≤1.05; 31MHz-60MHz: ≤1.25
Isolation: DC-15MHz: ≥50dB; 16-30MHz: ≥45dB; 31-60MHz: ≥38dB
Unselected port status: internal 50Ω virtual load
Automatically detect power requirements: 1-30MHz: ≥5W, 31-60MHz: ≥15W
Shell material: ABS
Product size: about 102.00x96.00x39.00mm
Product size: 4.02x3.78x1.54inch
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
