Max PV array power
|
5000W
|
6000W
|
|
MPPT Range @ operating voltage
|
120-450VDC
|
|
|
Max PV array open circuit voltage
|
500VDC
|
|
|
Max charging current
|
100A
|
|
|
Max efficiency
|
98%
|
|
|
AC Input
|
||
|
Frequency Range
|
50Hz / 60Hz
|
|
|
Voltage
|
230VAC
|
|
|
Selectable Voltage Range
|
170-280VAC (For personal computers)90-280VAC (For home appliances)
|
|
|
AC Output
|
||
|
Surge power
|
7000VA
|
11000VA
|
|
AC Voltage Rugulation
|
230VAC±5%
|
|
|
Efficiency PV to INV
|
97%
|
|
|
Wave Form
|
pure sine wave
|
|
|
Battery
|
||
|
Battery Voltage
|
48VDC
|
48VDC
|
|
Floating Charge Voltage
|
54VDC
|
54VDC
|
|
Net weight(KG)
|
11
|
12
|
|
Dimension D*W*H(MM)
|
300*440*100
|
|
|
Communication interface
|
USB / RS232 / WIFI / GPRS
|
|
Logistics information
Our products are located in Hong Kong, China, and the logistics speed depends on your specific location. According to our experience, it usually takes about 15-20 days of transportation time
