Description:
Features:
brand new and high quality
True 4-wire AC sine measurement, effectively avoid the influence of the test line and contact resistance.
Two functions interface, the original battery sorting function.
Built-in battery, mobile phone charger to charge, low power consumption + a variety of power-saving options.
Test range up to 200 ohms with a minimum resolution of 0.01 milliohms and less than 5 milliohms.
Press HOLD to enable the ZR function to measure internal resistance as low as 0.30-0.50 milliohms.
It can measure lead acid, lithium ion, lithium polymer, lithium iron phosphate, alkaline, dry battery, nickel hydrogen, nickel cadmium, button battery and so on.
Note: Read the instructions and instructions on the back of the instrument before using. It is forbidden to enter the ac signal and the dc voltage higher than 100 v.
Specification:
Internal resistance measurement:
Precision format: ± ([precision percentage] + [least significant digit]
Range minimum resolution accuracy
20mΩ 0.01mΩ 0.7%+7 (when ZR function is enabled)
200mΩ 0.1mΩ 0.5%+5
2Ω 1mΩ 0.5%+5
20Ω 10mΩ 0.5%+5
200Ω 0.1Ω 0.6%+5
In the range of 5%-95% of the gear position, if it is not within this range (less than 5% gear range range, or greater than 95% gear range range), the error may be greater than the above accuracy
Voltage measurement:
Range Accuracy ± (% reading + % range)
1V 0.15+0.015
10V 0.15+0.010
100V 0.15+0.015
Positive and negative symmetry error ± (0.012% + 5 words)
Temperature drift within normal use temperature (10°C-40°C) 100ppm/°C
Color: As pictures shown.
Size: app. 6x17cm(2.36x6.69in)
Quantity: 1 set
